• 마그넷
  • Tank type
  • 다이케스팅용 금형가능
  • Magnet
  • Tank type
  • Producting Die Casting
  • 자기진단기능
  • 간접냉각방식
  • 역상경보기능
  • 매체강제회수 (option기능)
  • Self - Diagnosis
  • Indirect Cooling Method
  • Phase Detecting Circuit
  • Air Suck-Back (option)


모델 MODEL
YMC-440
YMC-460
YMC-480
전원
Power source
AC 220/380V    50/60 Hz    3phase
온도제어범위
Temperature Control Range
오일 (Oil) 200℃
온도제어방식
Temperature Control
P.I.D (± 0.3)
냉각방식
Cooling Type
간접냉각(Indirect Cooling)
열매체
Heating Medium
오일(Thermo Oil)
모타 (kw)
Motor
1.1
1.5
2.2
최고토출압(kg/㎝3)
Max, Output Pressure
2.1
4.2
4.2
최고토출량(ℓ / min)
Max, Flow Rate
40
60
80
히타(kw)
Heater
6
8
6x2
분배구
Medium Supply
(10A) x 4
(10A) x 6
(10A) x 6
적용사출기(ton)
Injection Pressure Range
30~250
280~380
450~650
외형크기 m/m (W.L.H)
Dimmension
330x800x685
(660x800x685)
330x800x750
(660x800x750)
중량(kg)
Weight
55
65
85
